Features
VEEM’s passion for engineering excellence and manufacturing quality in every unit
No dry docking required for maintenance
Failsafe to passive operation in case of loss of control system power or error
Patented Active control system to maximise performance and safety.
Can be mounted off centreline if required
Can be mounted above main deck if required.
A single unit or multiple unit installation without any software adjustment. Just plug in and go.
Can be simply integrated with existing fins or active trim tabs.
Electronically controlled glycol cooling circuit maintains bearings and hydraulic oil at optimal temperatures even under extreme loads.
Flywheel and surrounding structure has infinite structural life for extreme safety.
Vibration sensors monitor bearing status and flywheel out-of-balance to provide advance warning of any issues.
Condition monitoring system provides advance notice of wear and tear to your computer or mobile device to allow scheduled maintenance.
Vibration and noise isolation mounts
Simple interface to vessel: electrical power and cooling water
No additional components like hydraulic power packs required. Just connect power and seawater.
Full colour touch screen display and control at unit
Repeater touch screens easily networked
Proprietary marinised control and monitoring hardware
TECHNICAL DETAILS
Angular Momentum:40 000 [N.m.s]
Rated Spin Speed:4800 [rpm]
Rated Torque:110 [kN.m]
Length:1630 [mm]
Width:1540 [mm]
Height:1100 [mm]
Mass:2100 [kg]
Cooling Water:15 [lpm]
Electric Power:10 – 15 kW (18 peak)
Technical specifications are approximate values and may change with installation and specific vessel requirements
