Yacht Engine
No price quoted.
Second Floor, Building 6, Dazhou Industrial Zone, Shijie Town, Dongguan City, Guangdong Province
Model (model P/N) ：D110L71-235 D110L71-205 D110L71-185 D110L71-165 D110L71-135
Number of turns (Turn)： 3.5T 4T 4.5T 5T 6T
(Voltage range) ：8-12S (29.6-50.4V) 10-14S (37-58.8V) 10-16S (37-67.2V) 14-18S (51.8-75.6V) 14-20S (51.8-84V) )
Max Spin Speed) (RPM)： 11844 12054 12432 12474 11340
Speed constant kV(RPM/V)： 235 205 185 165 135
Torque constant Kt(N*M/A)： 0.043 0.0483 0.0478 0.04773 0.0785
No-load current @8.4V(Current @8.4V without Loading)(A) ：15 9.0A 7.5 7 6.2
Maximum output power (Max Power) (KW)： 15.7 15.5 14.6 15.9 16
Maximum working current (Peak current) (A)： 630 560 490 440 370
Effeciency： 89% >87% 90% 91% 91%
Maximum output torque (max torque@60%)(N*M)： 26 25.8 25 26 26
Rated power @ benefit 80% (Rating Power) (KW)： 11.8 11.8 11.6 12.4 12.8
Rated Torque @ Benefit 80% (Rating Torque @ 80%) (N*M)： 15.3 15.9 15.5 16.2 16.8
Weight (KG)： 4.1 4.2 4.3 4.2 4.3
