YWC SERIES 15PPM BILGE OILY WATER SEPARATOR

YWC Type 15ppm Marine Oily Water Separator

15ppm bilge Separator, ten different models are fit for all kinds of shipsThis device can be used to treat oily bilge water in order to make it reach the requirements of IMO.MEPC.107 (49) resolution, which is also called 15ppm bilge separator. It contains type approved 15ppm bilge water separator ,15ppm bilge alarm andAutomatic shut down Device .
Technical Specifications YWC-
0.25 0.50 1.00 1.50 2.00 2.50 3.00 4.00 5.00
Rated capacity (m3/h) 0.25 0.50 1.00 1.50 2.00 2.50 3.00 4.00 5.00
Oil content of the discharged water <15ppm
Power of the electric heater(kw) 3 3 3 6 6 6 6 12 12
Electrical System AC 380V,50Hz,3&phi;/ AC 415V,50Hz,3&phi;/AC 440,60Hz,3&phi;/AC 480V,60HZ,3&phi;
Power of the electric motor 0.37kw 0.55kw 0.75kw 1.1kw 1.1kw 1.5kw 1.5kw 2.2kw 2.2kw
Suction head <6m-H2O
Pressure of the discharged water 5-10m-H2O
Outline Dimension(Length&times;Width&times;Height)(mm) 1000&times;600&times;1250
