Blue nylon insulated, jointed barrel with funnel seamless brass sleeve for easy insertion of wire
The notches and crimps of the female terminals provide excellent retention
Helps to complete wire disconnection quickly and easily
Use with a 0.25 "wide insert
Can accommodate line sizes 16-14 AWG
Durable brass for enhanced electrical conductivity and corrosion resistant tin plating
Temperature range -40-105 ℃ (-40-221 ℉)
Rated voltage is 600V for residential lines and 1000V for signs, fixtures or light sources
UL certified, CSA certified, RoHS 2011/65/EU standard
1000 / box
3M™ Scotchlok™ Standard female quick release terminals are notched and crimped for quick and easy disconnection while providing superior retention. The terminals have a nylon insulated pair joint cylinder and can withstand the temperature range -40-105 ° C (-40-221 ° F). The rugged brass construction provides excellent electrical conductivity while the tin coating resists corrosion.
3M™ Scotchlok™ Standard female quick release terminals are connected to convex inserts by a tongue that slides onto the inserts. The terminal has a butt-jointed cylinder covered with a funnel seamless brass sleeve for guiding the wire into place. Nylon insulated sleeve has friction resistance and adopts flaring form to facilitate fastening. It adopts step design to ensure no error crimping. UL certified, CSA certified, RoHS 2011/65/EU standard.
