Yacht Engine
No price quoted.
2nd Floor, Building C, Longcheng Industrial Zone, No. 39, Longguan West Road, Dalang Street, Longhua District, Shenzhen
Operating voltage range 12/24V (8V~36V)
Working current 60mA
Protection grade IP20
Installation location Installed inside the battery box
Number of battery monitoring strings: 12 strings
Dry contact output Peak current: <5A Rated current: 1A, 2 channels
I/O signal detection 1 way
CAN interface 1 way
485 interface 1 way
Single battery voltage sampling accuracy ≤0.2%FS
Single battery voltage sampling cycle ≤100ms
Temperature sensor layout 5 temperature detection points per 12 batteries
Temperature detection accuracy ≤±2℃
Equalization operation Passive equalization 70mA
Operating temperature range -40~85℃
Operating humidity range 0～95%
