Capacity:Max. 50 bags/min (It depends on packing component.) |
Packing Material:NWF , Nylon/PET mesh, Bio-degradable |
Packing Method:Sticking and cutting by ultrasonic |
Bag Size: (Pyramid) : 58~78mm (Plane) : L 45-100mm, W 58-78mm |
Feeding System:5 load-cells |
Filling Range:2~12g |
Power Supply:AC220V, 50/60Hz, 3P, 4.0KW |
Pneumatic Pressure:5Kg/cm2 (0.5MPa) |
Dimension:1170mm(L) x 1060mm(W) x 2050mm(H) |
Weight:450Kg |
Standard Accessories: Touch panel 、Tag detector、Ultrasonic overload protection、Liner & waste collection device |
